Kzyee KM301 - Quick Test Function; Initiating Quick Test and Inputting Capacity; Viewing Quick Test Results

OBD & Battery Analysis Scanner
- 13 -
Quick Test
1. From main menu of battery test,
press UP/DOWN key to select the
Quick Test Ah, then press OK to
confirm.
Main Menu 2/4
1.Battery Test
2.Quick Test Ah
3.Review Data
4.Print Data
Figure32
2. Use Up/Dowm/Left/Right button to
input the rated battery capacity—xx
AH, then press OK.
Input Ah Value
50Ah
Please input the A-HR value in the
lable of the battery
Figure33
3. If the battery power is low, the screen
will automatically prompt [Battery
power is low. Continue?], then
press OK to continue.
Battery power is low.
Continue?
Figure34
4. Screen auto prompt Testing**
Please wait for about 3 seconds.
Battery Test
Testing
Figure35
5. Screen displays battery test result
as follows.Press ESC to exit.
Battery Test
Healthy: 85% 410A(CCA)
Charge: 0% 11.97V
Internal R= 6.61mΩ
Rated: 400A
GOOD,RECHARGE
Figure36
