OBD & Battery Analysis Scanner
- 8 -
Battery Test Result
Includes 5 types as following:
Battery Test
Healthy: 96% 490CCA
Charge: 98% 12.64V
Internal R= 6.1mΩ
Rated: 500A
GOOD
Figure14
The battery is without any problem,
please be relaxed to use!
2.
Good, Recharge
Battery Test
Healthy: 78% 440CCA
Charge: 30% 12.20V
Internal R= 7.2mΩ
Rated: 500A
GOOD,RECHARGE
Figure15
Good battery but low current, recharge
before using.
3.
Replace
Battery Test
Healthy: 46% 490CCA
Charge: 80% 12.68V
Internal R= 18.1mΩ
Rated: 500A
REPLACE
Figure16
The battery is near to or already reached
the end of the using life, replace battery,
otherwise, bigger danger will be followed.
Battery Test
Healthy: 0% 0CCA
Charge: 80% 10.64V
Internal R= 45.2m
Ω
Rated: 500A
BAD CELL,REPLACE
Figure17
Battery interior damaged, bad cell or
short circuit, replace battery.
5.
Charge, Retest
Battery Test
Healthy: 39% 310CCA
Charge: 20% 12.08V
Internal R= 30.1mΩ
Rated: 500A
CHARGE,RETEST
Figure18
Unstable battery shall be recharged and
retested to avoid error. If same test
result appears after recharge and retest,
the battery is regarded as damaged,
replace the battery.
