On-Board Monitor Test
Mode $06 Request On-Board Monitoring Test
Results for Specific Monitored Systems
View test data for Non ContinuousMonitors.
This section contains advanced
functions. Some data may need to be
interpreted by a qualified technician.
Note: Not all vehicles return the same
data, results may vary from the examples
given herein.
1. From Diagnostic Menu, use the Up/
Down button to select On-Board Mon.
Test, then press OK.
2. Select vehicle manufacturer.
Figure 112
3. Select and view Monitors, their tests
and results as needed.
On-Board Mon. Test 1/10
A/F Sensor Bank Sensor 1
H02S Bank Sensor 2
Catalyst Mon. Bank 1 ?
EVAP
EGR Heater Mon.B1S2
Misfire
Misfire
Figure 111
Figure 113
Note: If necessary, have a qualified
technician Interpret the data.
Vehicle Manufacturer 1/28
BUICK
BMW
CADILLAC ?
CHEVROLET
CHRYSLER
FORD
Diagnostic Menu 7/11
Read Codes
Erase Codes
Live Data ?
View Freeze Frame
I/M Readiness
02 Monitor Test
On-Board Mon. Test
