Custom Data Set - Record Select PIDs (continued)
7. After the passenger determines
that recording is finished, stop
driving. Data can be viewed
immediately or saved to view later.
8. Interpret data according to
“Playback Data” on page 34.
Note: If necessary, have a qualified
technician interpret the data.
NO
YES
Recording Done!
Playback data?
Record Data
Figure 99
Playback Live PID Data
This section contains advanced
functions. Some data may need to be
interpreted by a qualified technician.
1. From Diagnostic Menu, use theUp/
Down button to select Live Data,
then press OK.
Figure 101
3. From Select Memory, use the Up/
Down button to select a memory
location marked with an asterisk (*),
then press OK.
Figure 100
2. From Live Data, use the Up/ Down
button to select Playback Data,
then press OK.
Figure 102
4. Interpret data according to
“Playback Data” on page 34.
Note: If necessary, have a qualified
technician Interpret the data.
