Kzyee KM301 - Battery Test Procedure Details; Setting Test Standards and AH Value; Viewing Battery Test Results

OBD & Battery Analysis Scanner
- 7 -
6. Use the Up/Down button to go to
previous or next screen, select
Battery Test Standard, then press
OK.
Selection Test Standard
CCA
1/10
Figure9
7. Use the Up/Down/Left/Right button
（to increase/ decrease）to input AH
value, then press OK.
Setting Rate
500A CCA
Figure10
8. If the battery power is low, the screen
will automatically prompt [battery
power is low, continue?], press OK to
continue; if the battery power is
normal, the screen will directly
display Testing**.
Battery power is low.
Continue?
Figure11
9. Screen auto prompt Testing**
Please wait for about 3 seconds.
Battery Test
Testing**
Figure12
10. Screen displays battery test result
as follows. Press ESC to exit.
Battery Test
Healthy: 88% 521A(CCA)
Charge: 0% 11.98V
Internal R= 5.19mΩ
Rated: 500A
GOOD,RECHARGE
Figure13
