L-Acoustics A15 Series User Manual

Rigging procedures
This step requires two operators.
Hold the enclosure by the handle until the rigging system is locked.
4. One by one, secure additional enclosures under the array.
Connect each enclosure on both sides before adding the next one.
SHLAK!
Final check
Visually check that no yellow labels are visible.
Manually check that all linking points are secured.
A15 owner's manual (EN) version 1.2 51

L-Acoustics A15 Series Specifications

General

Nominal impedance	8 ohms
Frequency Response	44 Hz - 20 kHz
Maximum SPL	141 dB
Amplification	LA4X / LA8 / LA12X
Weight	33 kg
LF Transducers	1 x 15'' neodymium
HF Transducers	1 x 3'' diaphragm compression driver
Power Handling	800 W
Connectors	2 x 4-point speakON
