L-Acoustics K2 - Page 103

Rigging procedures
3. Attach the lower K2 enclosures rear rigging arm to the back of the array:
a) Turn the wheels inside the dolly.
b) Pull back the bottom enclosures while lowering the array until the array and the top enclosure of the block are in
contact.
c) Slide the arm upward and secure it with the pin using the LINK hole.
K2 owner's manual (EN) version 1.1 103
