Corrective maintenance
D/R - RIGGING PINS
Tools
• riveting pliers
Repair kit
KR PIN163
Kit K1 6 ball head pins
×6 ×6 ×6
163 S142 S254
ball-locking pin Ø1/2"with lanyard M4×10 rivet M4.8×18 rivet
The S254 are not used (represented for comparison)
Exploded view
For safety reasons, always use the new screws and spare parts provided in the KR.
Position the at side of the steel tab toward the rigging element.
