Corrective maintenance
D/R - RIGGING PINS
Tools
• riveting pliers
Repair kit
KR PIN1394
Kit 2 x pin 1394
×2 ×2
1394 S254
ball-locking pin Ø3/8" with lanyard M4.8×18 rivet
Exploded view
For safety reasons, always use the new screws and spare parts provided in the KR.
Position the at side of the steel tab toward the rigging element.
158 K2 owner's manual (EN) version 1.1
