lancer IBD 22 - Page 35

35
Item Part No. Description
1* 82-1879/01 Electrical Box Assy, Pre-Mix, IBD22*
- 52-1902/01 Ballast Assy, 115V
2 04-0504 Screw, 8 - 18 X 0.375, PHD
3 52-1584 Harness Assy, Light, Black
4 04-0237 Screw, 8 - 32 x 0.250, PH, MS, SS
5 30-6152 Bracket, Right, Light, IBD
6 11-0295 Socket, 660W/600V MAX
7 52-1583 Harness Assy, Light, White
8 30-6153 Bracket, Left, Light, IBD
9 02-0005 O-Ring, 2-010
10 52-2450 Harness Assy, Detector
11 06-2488 Label, Ice Link Tag, IBD
12 02-0406 Seal, Shaft, Motor, IBD
13 82-1874H Tank Assy, Foamed, Pre-Mix, IBD22
14 05-1859 Body, Detector, Sensor, Plug
15 05-1858 Body, Emitter, Sensor, Plug
16 02-0155 O-Ring, 2-015
17 52-2353 Body Assy, Detector, Sensor
18 52-2352 Body Assy, Emitter, Sensor
19 30-8468 Wrapper Assy, IBD22, Round
20** 12-0097 Switch, Key Lock**
21 30-6149 Cover, Cut Out, Wrapper, IBD
22 06-1580 Label, Patent
23 52-2449 Harness Assy, Emitter, IBD
24 07-0211 Washer, Shipping Base
25 04-0203 Screw, 3/8 - 16 X 1.00, FHD
26 90-0756 Shipping Board, IBD, 22 Inch Wide
27 82-1556 Drive Assy, Motor, IBD, 115V
28 04-0069 Screw, 10 - 16 X 0.500
29 30-6147 Cover, Motor, IBD
-- 05-1555 Rear Bearing (Not Shown)
REF Ballast Assy Components (Not Shown)
-- 12-0104 Starter, 115VAC, 14-20 WA
-- 12-0194 Starter, Base
REF Electrical Box Assy Components (Not Shown)
*-- 52-1436/05 PCB Assy, (Available as Spare Part)
*-- 25-0039 120V-24V Transformer, (Available as
Spare Part)
*-- 25-0047 75VA-24V Transformer, (Available as
Spare Part)
*-- 25-0040 220V-24V Transformer, (Available as
Spare Part)
**-- 81-0125 Key, (Available as Spare Part)
