Lantronix XPort User Manual

Introduction to XPort™
1.10 Technical Specifications
Table 4 - Technical Specs
Category Description
CPU, Memory Lantronix DSTni-LX 186 CPU, 256 KB zero wait state SRAM
512Kbytes Flash, 2KB Boot ROM
Firmware Upgradeable via TFTP and serial port
Reset Circuit 200msec power up/down reset pulse. Reset triggered at 3.08V Manual
reset input supplies a 200msec reset.
Serial Interface CMOS (Asynchronous) 3.3V-level signals. (Not 5V tolerant)
Baud rate software selectable (300 to 230400bps)
Serial Line Formats 7 or 8 data bits, 1-2 Stop bits, Parity: odd, even, none
Modem Control DTR, DCD, CTS, RTS
Flow Control XON/XOFF (software), CTS/RTS (hardware), None
Programmable I/O 3 PIO pins (software selectable) Sink or source 8ma max.
Network Interface RJ45 Ethernet 10Base-T or 100Base-TX (Auto-sensing)
Compatibility Ethernet: Version 2.0/IEEE 802.3
Protocols Supported ARP, UDP/IP, TCP/IP, Telnet, ICMP, SNMP, DHCP, BOOTP, TFTP, Auto
IP, SMTP, and HTTP
LEDs 10Base-T & 100Base-TX Activity, Full/half duplex. Pins 6 & 8 can also
drive external LEDs for XPort™ status & diagnostics.
Management Internal web server, SNMP (read only)
Serial login, Telnet login
Security Password protection, Locking features, optional Rijndael 128-bit encryption
Internal Web Server Serves static web pages and Java applets
Storage capacity: 384KBytes
Weight 0.34 oz (9.6 grams)
Material Metal shell, thermoplastic case
Temperature Operating range: -40°C to +85°C (-40°F to 185°F)
Relative Humidity Operating: 5% to 95% non-condensing
Shock/Vibration Non-operational shock: 500 g's, Non-operational vibration: 20 g's
Warranty 1-year limited warranty
Included Software Windows™ 98/NT/2000/XP based XPort™ Installer configuration software
and Windows™ based Comm Port Redirector
EMI Compliance
Radiated & conducted emissions - complies with Class B limits of EN
55022:1998
Direct & Indirect ESD - complies with EN55024:1998
RF Electromagnetic Field Immunity - complies with EN55024:1998
Electrical Fast Transient/Burst Immunity - complies with EN55024:1998
Power Frequency Magnetic Field Immunity - complies with EN55024:1998
RF Common Mode Conducted Susceptibility - complies with
EN55024:1998
1-6 XPort™ User Manual and Development Kit

Lantronix XPort Specifications

General

Data Link Protocol	Ethernet, Fast Ethernet
Connectivity Technology	Wired
Form Factor	Embedded
Category	Embedded Systems
Interface	Serial
Serial Ports	1
Operating Temperature	0°C to 70°C
