Lantronix XPort User Manual

Network Configuration Using UDP
9.3.1 Channel Parameters
Use the following table to select setup record parameters for Channels 1:
Table 27 - Channel Parameters
Byte(s)
(Channel 1)
Function
16
Interface Mode (see
Table 11 - Interface Mode Options on
page 4-12)
17 Line Speed
Bits 7-5: Reserved
Bits 4-0: Baud Rate (see
Table 28 - Baud Rate Settings)
18
Flow Control (see
Table 13 - Flow Control Options on page 4-
12)
19 Reserved
20-21 Own TCP port low-byte, high-byte (Intel)
22-23 Remote TCP port low byte, high-byte (Intel)
24-27 Remote IP address (low/high low/high)
28
Connect Mode (see
Table 14 - Connect Mode Options on
page 4-14)
29
Disconnect Mode (see
Table 17 - Disconnect Mode Options
on page 4-20)
30 Disconnect w/ inactivity time-out, minutes (00 if unused)
31 Disconnect w/ inactivity time-out, seconds (00 if unused)
32-33 Characters to trigger send immediately (sendchar)
34
Flush mode (see
Table 18 - Flush Mode Options on page 4-
20)
35
Pack Control (see
Table 19 - Pack Control Options on page
4-21)
36-47 Reserved (0)
48-63 a) Terminal name for Telnet terminal type option (15 characters
max), 0-terminated. If set and Bit 6 in Disconnect Mode is set,
Telnet connection will be assumed.
b) Password for Passworded Socket Connection (Bit 4 in
Disconnect Mode Set).
9-6 XPort™ User Manual and Development Kit

Lantronix XPort Specifications

General

Data Link Protocol	Ethernet, Fast Ethernet
Connectivity Technology	Wired
Form Factor	Embedded
Category	Embedded Systems
Interface	Serial
Serial Ports	1
Operating Temperature	0°C to 70°C
