Larson Davis System 824 Training Manual

2/19/98 Data D 4-1
CHAPTER
4
Data D
The DATA key D provides access to the data storage
and recall functions of the System 824. Data files are
stored in the 824’s internal memory. First, verify that
the 824 is still running (running figure in top right cor-
ner). If it is not, press RUN/STOP s.
Step 1 With the instrument stopped, press D to
enter the Data Files menu.
If you have never stored data with the 824, it will
appear as above. If there is data currently stored in the
824’s memory, the Data Files screen will appear as it
does below.
Notice that the “Store Data” function is currently high-
lighted. It signifies that the 824 is now ready to store
data.
To store the data, press the c. If the 824 is running (as
it should be now), you will see the following warning

Larson Davis System 824 Specifications

General

Brand	Larson Davis
Model	System 824
Category	Measuring Instruments
Language	English
