X-Stream Operator’s Manual

WM-OM-E Rev I 151

maxp Maximum Population

Definition:

The count (vertical value) of the highest population bin in a histogram.

Description:

Each bin between the parameter cursors is examined for its count. The highest

count is returned as maxp.

Example:

Here, maxp is 14.
