152 WM-OM-E Rev I

mode Mode

Definition:

The value of the highest population bin in a histogram.

Description:

Each bin between the parameter cursors is examined for its population count.

The leftmost bin with the highest count found is selected. Its center value is

returned as mode.

Example:

Here, mode is 150 mV.
