LeCroy WavePro 7100A

X-Stream Operator’s Manual
WM-OM-E Rev I 187
Delta delay delay: Computes time between
50% level of two sources.
Time between midpoint
transition of two sources
Standard parameter.
Dj Effective Amount of deterministic jitter
(estimated) in a signal
Available with SDA
option.
DOV Differential Output Voltage of a
100Base-T signal
Available with ENET
option.
Dperiod@level Adjacent cycle deviation
(cycle-to-cycle jitter) of each cycle
in a waveform
Reference levels and
edge-transition polarity
can be selected.
Hysteresis argument
used to discriminate
levels from noise in
data.
Available with JTA2 and
XMAP options.
Standard in SDA100G
scopes.
Droop FG 1000Base-T test mode 1 droop
from F to G
Available with ENET
option.
Droop HJ 1000Base-T test mode 1 droop
from H to J
Available with ENET
option.
Dtime@level t at level: Computes transition
between selected levels or sources.
Time between transition
levels of two sources, or from
trigger to transition level of a
single source
This measurement gives the
time of the source 2 edge
minus the time of the source
1 edge.
Reference levels and
edge-transition polarity
can be selected.
Hysteresis argument
used to discriminate
levels from noise in
data.
Standard parameter.
Dtrig Time Time from last trigger to this trigger Standard in
WaveRunner 6000A,
WavePro 7000A,
WaveMaster, and
sampling scopes.
Duration For single sweep waveforms, dur is
0; for sequence waveforms: time
from first to last segment's trigger;
for single segments of sequence
waveforms: time from previous
segment's to current segment's
trigger; for waveforms produced by
a history function: time from first to
last accumulated waveform's
trigger.
Time from first to last
acquisition: for average,
histogram or sequence
waveforms
Standard parameter.
