188 WM-OM-E Rev I
Duty@level Percent of period for which data are
above or below a specified level.
Reference levels and
edge-transition polarity
can be selected.
Hysteresis argument
used to discriminate
levels from noise in
data.
Available with JTA2 and
XMAP options.
Duty cycle Duty cycle: Width as percentage of
period.
width/period Standard parameter.
Dwidth@level Difference of adjacent width above
or below a specified level.
Reference levels and
edge-transition polarity
can be selected.
Hysteresis argument
used to discriminate
levels from noise in
data.
Available with JTA2 and
XMAP options.
Standard in SDA100G
scopes.
Edge@level Number of edges in waveform. Reference levels and
edge-transition polarity
can be selected.
Hysteresis argument
used to discriminate
levels from noise in
data.
Available with JTA2,
USB2, SDA, and XMAP
options.
Standard in SDA100G
and WavePro 7000A
scopes.
Ext Ratio Ratio of the power levels of an eye
diagram
Available with SDA and
SDM options.
Standard in SDA,
SDA100G, and
WaveExpert scopes.
