LeCroy WavePro 7100A

X-Stream Operator’s Manual
WM-OM-E Rev I 189
Excel Performs measurements in Excel
by transferring one or two
waveforms and reading the
resulting parameter value.
Available with XMAP
and XDEV options.
Standard on
DDA-5005A scope.
Excel must be loaded on
the instrument.
Eye AC RMS Root mean square of data within
one UI
Standard in SDA and
WaveExpert scopes.
Eye Amplitude Difference of the levels of an eye
diagram
Available with SDA and
SDM options.
Standard in SDA,
SDA100G, and
WaveExpert scopes.
Eye BER Bit Error Rate estimated from an
eye diagram
Available with SDA and
SDM options.
Standard in SDA,
SDA100G, and
WaveExpert scopes.
Eye Bit Rate One over duration of one UI
measured on an eye
Standard in SDA and
WaveExpert scopes.
Eye Bit Time Duration of one UI measured on an
eye
Standard in SDA and
WaveExpert scopes.
Eye Crossing Level of the crossing in an eye
diagram
Available with SDA and
SDM options.
Standard in SDA,
SDA100G, and
WaveExpert scopes.
Eye CrossN Time of first crossing 50% level with
negative edge of an eye relative to
trigger or eye reference
Standard in SDA and
WaveExpert scopes.
Eye CrossP Time of first crossing 50% level with
positive edge of an eye relative to
trigger or eye reference
Standard in SDA and
WaveExpert scopes.
Eye Cyc Area The area under the mean
persistence trace under first UI
Standard in SDA and
WaveExpert scopes.
Eye Delay Time of first crossing of an eye
relative to trigger or eye reference
Standard in SDA and
WaveExpert scopes.
Eye Delt Dly Delay of crossing times between
two eyes
Standard in SDA and
WaveExpert scopes.
Eye FallTime Fall time of the mean of persistence
data
Standard in SDA and
WaveExpert scopes.
