LeCroy WavePro 7100A

190 WM-OM-E Rev I
Eye Height Size of the vertical opening of an
eye diagram
Available with SDA and
SDM options.
Standard in SDA,
SDA100G, and
WaveExpert scopes.
Eye Mean Mean level of an eye Standard in SDA and
WaveExpert scopes.
Eye Open Fac Eye opening factor measured within
the eye aperture
Standard in SDA and
WaveExpert scopes.
Eye OverN Negative overshoot measured on
an eye
Standard in SDA and
WaveExpert scopes.
Eye OverP Positive overshoot measured on an
eye
Standard in SDA and
WaveExpert scopes.
Eye Pk Noise Peak-to-peak noise of a level of an
eye diagram
Standard in SDA and
WaveExpert scopes.
Eye PkPk Jit Peak-to-peak jitter measured on
eye persistence
Standard in SDA and
WaveExpert scopes.
Eye Pulse Wid The width of the eye measured at
mid level
Standard in SDA and
WaveExpert scopes.
Eye Q Factor Q factor measured within the eye
aperture
Available with SDA and
SDM options.
Standard in SDA,
SDA100G, and
WaveExpert scopes.
Eye RiseTime Rise time of the mean of
persistence data
Standard in SDA and
WaveExpert scopes.
Eye RMS Jit Root mean square jitter of an eye Standard in SDA and
WaveExpert scopes.
Eye SD Noise The standard deviation of data on
one eye level
Standard in SDA and
WaveExpert scopes.
Eye SgToNoise Signal to noise of an eye diagram Standard in SDA and
WaveExpert scopes.
Eye SupRatio Suppression ratio of an eye Standard in SDA and
WaveExpert scopes.
Eye Width Size of the horizontal opening of an
eye diagram
Available with SDA and
SDM options.
Standard in SDA,
SDA100G, and
WaveExpert scopes.
