LeCroy WavePro 7100A

X-Stream Operator’s Manual
WM-OM-E Rev I 195
Hist rms Root mean square of the values in a
histogram.
Available with DDM2,
JTA2, XMATH, XWAV,
CAN02, SDA, and
XMAP options.
Standard in
DDA-5005A, SDA100G,
and sampling scopes
Hist sdev Standard deviation of values in a
histogram.
Available with DDM2,
JTA2, XMATH, XWAV,
CAN02, SDA, and
XMAP options.
Standard in
DDA-5005A, SDA100G,
WaveExpert, and
sampling scopes.
Hist top Value of the right-most of the two
most populated histogram peaks.
Available with DDM2,
JTA2, XMATH, XWAV,
CAN02, SDA, and
XMAP options.
Standard in
DDA-5005A, SDA100G,
WaveExpert, and
sampling scopes.
Hist X@peak The value of the nth highest
histogram peak.
Applies only to
histograms.
Available with JTA2,
XMATH, XWAV,
CAN02, DDM2, SDA,
and XMAP options.
Standard in
DDA-5005A, SDA100G,
and WaveExpert
scopes.
Hold time Time from the clock edge to the
data edge. You can set levels,
slope, and hysteresis independently
for Hold Clock and Hold Data. See
also Setup parameter.
Reference levels and
edge-transition polarity
can be selected.
Hysteresis argument
used to discriminate
levels from noise in
data.
Available with JTA2,
ENET, USB2, SDA, and
XMAP options.
Standard in SDA100G
scopes.
