LeCroy WavePro 7100A

196 WM-OM-E Rev I
Hparam Script Visual Basic (or Java) script which
produces a measurement from one
or two input
histogram results
Available with XMAP,
ASDA, and XDEV
options.
Standard in
DDA-5005A.
Jitter Filter Jitter in the specified frequency
band. Generates a time sequence
of jitter measurements that are
filtered by the selected band-pass
filter.
Available with ASDA
option.
Last Time from trigger to last (rightmost)
cursor.
Time from trigger to last
cursor
Indicates location of
right cursor. Cursors are
interchangeable: for
example, the right
cursor may be moved to
the left of the left cursor
and first will give the
location of the cursor
formerly on the left, now
on right.
Standard parameter.
Level@X Gives the vertical value at the
specified x position. If the x position
is between two points, it gives the
interpolated value. When the
Nearest point checkbox is
checked, it gives the vertical value
of the nearest data point.
Standard parameter.
Local base Value of the baseline for a local
feature.
Hysteresis argument
used to discriminate
levels from noise in
data.
Available with DDM2
option.
Standard in
DDA-5005A.
Local bsep Local baseline separation, between
rising and falling slopes.
Hysteresis argument
used to discriminate
levels from noise in
data.
Available with DDM2
option.
Standard in
DDA-5005A.
