202 WM-OM-E Rev I
Param Script Visual Basic or Java script that
produces a measurement from one
or two input waveforms.
Available with XMAP,
XDEV, and ASDA
options.
Standard in
DDA-5005A.
Peak Mag Peak mag away from a baseline.
Note: the measure gate must
include more of the baseline than
any other single level.
Available with ENET
option.
Peaks Number of peaks in a histogram. Available with DDM2,
JTA2, XMATH, XWAV,
CAN02, SDA, and
XMAP options.
Standard in
DDA-5005A, SDA100G,
and WaveExpert
scopes.
Peak to peak Peak-to-peak: Difference between
highest and lowest points in
waveform. Unlike ampl, does not
assume the waveform has two
levels.
maximum - minimum Gives a similar result
when applied to time
domain waveform or
histogram of data of the
same waveform. But
with histograms, result
may include
contributions from more
than one acquisition.
Standard parameter.
Percentile Horizontal data value that divides a
histogram so the population to the
left is xx% of the total.
Available with DDM2,
JTA2, XMATH, XWAV,
CAN02, SDA, and
XMAP options.
Standard in
DDA-5005A, SDA100G,
WaveExpert, and
sampling scopes.
Per DCD Amount of jitter due to duty cycle
distortion
Standard in SDA and
WaveExpert scopes.
Per Duty Cyc Duty cycle measured on a
persistence
Standard in SDA and
WaveExpert scopes.
