Nb Power Provides a measurement of the
power at a specific frequency of a
waveform (narrow band).
Available with DDM2,
XMATH, PMA2, SDA,
and XMAP options.
Standard in DDA-5005A
and SDA100G scopes.
N-cycle jitter Peak-to-peak jitter between edges
spaced n UI apart.
Compares the expected time
to the actual time of leading
edges n bits apart.
Available in SDA
analyzers.
NLTS Provides a measurement of the
nonlinear transition shift for a prml
signal.
Available with DDM2
option.
Standard in
DDA-5005AA.
Num Points Number of points in the waveform
between the cursors.
Standard parameter.
One Level One level of an eye diagram Available with SDA and
SDM options.
Standard in SDA,
SDA100G, and
WaveExpert scopes.
Overshoot- Overshoot negative: Amount of
overshoot following a falling edge,
as percentage of amplitude.
(base - min.)/ampl x 100 Waveform must contain
at least one falling edge.
On signals not having
two major levels
(triangle or saw-tooth
waves, for example),
may not give predictable
results.
Standard parameter.
Overshoot+ Overshoot positive: Amount of
overshoot following a rising edge
specified as percentage of
amplitude.
(max. - top)/ampl x 100 Waveform must contain
at least one rising edge.
On signals not having
two major levels
(triangle or saw-tooth
waves, for example),
may not give predictable
results.
Standard parameter.
Overwrite Ratio of residual-to-original power
of a low frequency waveform
overwritten by a higher frequency.
Available with DDM2
option.
Standard in
DDA-5005A.
