200 WM-OM-E Rev I
Maximum Measures highest point in
waveform. Unlike top, does not
assume waveform has two levels.
Highest value in waveform
between cursors
Gives similar result
when applied to time
domain waveform or
histogram of data of
same waveform. But
with histograms, result
may include
contributions from more
than one acquisition.
Computes horizontal
axis location of
rightmost non-zero bin
of histogram -- not to be
confused with maxp.
Standard parameter.
Mean Average of data for time domain
waveform. Computed as centroid of
distribution for a histogram.
Average of data Gives similar result
when applied to time
domain waveform or
histogram of data of
same waveform. But
with histograms, result
may include
contributions from more
than one acquisition.
Standard parameter.
Median The average of base and top
values.
Average of Base and Top. Standard parameter.
Minimum Measures the lowest point in a
waveform. Unlike base, does not
assume waveform has two levels.
Lowest value in waveform
between cursors
Gives similar result
when applied to time
domain waveform or
histogram of data of
same waveform. But
with histograms, result
may include
contributions from more
than one acquisition.
Standard parameter.
Nb phase Provides a measurement of the
phase at a specific frequency of a
waveform (narrow band).
Available with DDM2,
XMATH, SDA, and
XMAP options.
Standard in DDA-5005A
and SDA100G scopes.
