CS102 SNMP Card
User Manual
20
Identification
UPS Identification
Item
Description
UPS Model
The UPS model name (e.g., “Daker DK Plus 3000”)
UPS Name
The unique name of the UPS, as configured by the Administrator
(default is the same as displayed in "UPS Model")
UPS Serial Number
The serial number of the UPS
UPS Firmware Revision
The firmware version of the UPS
CS102 Firmware Revision
The firmware version of the CS102 SNMP card
UPS Type
Type of the UPS: “On-Line, Off-Line, Line-Interactive,
3 Phase” or “Three-phase in One Out”
UPS Protocol
This allows the user to choose the model/family of the UPS
connected to the CS102
UPS Baud Rate
It allows to select the communication parameters between the
CS102 and the UPS. Except in very special cases, leave the default
setting (“Auto Detect”)
Rating Group
Item
Description
Input Rating Voltage
The nominal input voltage (P-N) of the UPS, in Volts
Input Frequency
The nominal input frequency of the UPS, in Hertz
Output Rating Voltage
The nominal output voltage (P-N) of the UPS, in Volts
Output Frequency
The nominal output frequency of the UPS, in Hertz
Output Rating Current
The nominal output current of the UPS, in Ampere
Rating Battery Voltage
The total nominal voltage of the UPS battery, in Volts
Output Rating VA
The nominal apparent output power of the UPS, in VA
Output Rating Watt
The nominal active output power of the UPS, in Watt
UPS Control
This section let you perform control such as stopping/starting the UPS and running a battery test.
Item
Description
UPS Shutdown Delay
The delay (in seconds) that the UPS stays on after being told to shut
down; it will be added to any shutdown schedule you set.
To avoid improper shutdown of computers, this time should always
be greater than the time required for the computers to shut down
properly
UPS Sleep Time
The duration (in minutes) that the UPS remains in sleep mode.
During this mode, the UPS does not provide output power
regardless of the status of the input line. After the specified time,
the output power will resume.
