CS102 SNMP Card
User Manual
21
Item
Description
UPS Shutdown Type
Allows you to choose whether to switch off the entire UPS or just
its outputs, in case of executing one of the commands in the "UPS
Control Action" drop-down menu
UPS Control Action
◼ Turn Off UPS with Delay: the UPS (or its outputs) shuts down
after the time specified in “UPS Shutdown Delay”
◼ UPS Sleep: it causes the UPS (or its outputs) to shut down after
the delay time configured in "UPS Shutdown Delay" and stay off
for the time specified by "UPS Sleep Time". Once the specified
time has elapsed, the UPS (or its outputs) will automatically turn
back on
◼ Turn On UPS / Cancel UPS Shutdown: it causes the UPS to cancel
any shutdown processes in progress. If the UPS has already shut
down, immediately turn the UPS (or its outputs) back on
◼ Turn On/Off Beep: enable or disable the UPS buzzer
Battery Test Setting Time
Allows you to set the total time for the battery test when “Timed
Test” has been selected in the “Battery Test Command” drop down
menu
Battery Rated Capacity
Sets the remaining battery capacity at which the "Test Until Battery
Rated Capacity" test will end
Battery Test Command
◼ None: no action (default)
◼ Quick Battery Test: performs battery test for a short time
(typically 10 seconds to 2 minutes - UPS dependent)
◼ Test Until Battery Low: runs the battery test until the battery is
empty
◼ Timed Test: run the battery test for the period set in the “Battery
Test Setting Time” parameter
◼ Test Until Battery Rated Capacity: performs a battery test until
the battery charge percentage drops to the level set in "Battery
Rated Capacity" parameter
◼ Cancel Test: cancel the battery test
◼ Clear Test Information: clears information about the last battery
test performed by the CS102
Last Test Start Time
The start time of the last battery test
Last Test Elapsed Time
The elapsed time of the last battery test
Last Test Result
The result of the last battery test
Thresholds
This lets you set the temperature and load threshold point for the UPS.
Item
Description
Over Temperature Set Point
Set the upper temperature limit of the UPS. When the UPS
temperature exceeds this limit, the CS102 takes the action
specified in the "UPS Management → Schedule and Shutdown
→ Event Shutdown" page. Range: 10~100 °C
