Service Manual JET3
136 Rev. 1.0
13. Close the gutter tube with the button <Close Nozzle> (1), switch the <Ink on> (2) and
activate the <Ink-Flow-Sensor> (3).
1 – Button <Close Nozzle>
2 – Button <Ink on>
3 – Button <Ink Flow Sensor>
14. Bring the drop production unit into the print position. Then install the inner cover and
tighten it. Don’t smash or brake any cables and pipes during this action.
15. Check the jet for the right position in the gutter and the electrodes.
1
2
3
Pull the allen key carefully out of
the bearing block again.
