Leibinger JET3 up - Print Head Adjustment (SK6)

Service Manual JET3
Rev. 1.0 109
4) Print head adjustment
Necesary tools: sixfold magnifier, 2mm hex key, T6x50 torx.
1. Switch on the JET3up and wait while the system is bleeding.
2. Touch the softkey <Hydraulic settings> (1) and change to the menu <Printhead> (2).
Turn off the function <Ink-Flow-Sensor> (3).
1 – Softkey <Hydraulik settings>
2 – Menu <Printhead>
3 – Button <Ink Flow Sensor>

1
2
3
