Leibinger JET3 up - Movable Underframe for Jet3 Up; Fastening Options

Service Manual JET3
Rev. 1.0 23
Figure 4
For this it is expedient to place the device on a device support.
The device has four fastening possibilities for secure setting up and should be screw
connected at the place of setting up.
Figure 5
Fastening options
A place of setting up with sufficient load bearing capacity and stability must
be chosen. Prior to assembly the place of setting up must be cleaned of
dirt and contamination (residue of lubricants etc.).
Movable underframe
for JET3up:
