Service Manual JET3
108 Rev. 1.0
9. Close the nozzle seal completely by pressing the button <arrow> (1). Actuate several
times in quick succession the buttons <Ink on> (2) / <Ink off> (3). Press <Jet Adjust>
(4) and wait until the nozzle seal is open. Check the jet position inside the gutter.
1 – Button <Close Nozzle>
2 – Button <Ink on>
3 – Button <Ink off>
4 – Button <Jet adjust>
10. Close the nozzle seal again and fix the inside cover.
(Caution: Watch out for damaging any tubes or cables!)
11. Final checkup on the correct head adjustment and function check-out.
3
4
1
2
