Service Manual JET3
Rev. 1.0 179
13. Check up all connector cables again.
If the LCD-display-cable is not connected correctly, the illustration of the display could
be defective.
14. Close the front door.
15. Plug in the main plug
16. Switch on the JET3up and calibrate the touch display.
Necessary Tool:
Allen key (SW 4mm)
Touch Display Pen
Art. Nr. 54-002763 S
