Service Manual JET3
212 Rev. 1.0
3. Open the front door of the electronic cabinet.
4. Remove the cover of the power supply.
For disconnect the power supply it is advantageous to remove the cover of the power
supply at first.
5. Disconnect the wire for the power supply of the fan from the board
Allen key (SW 4mm)
Unscrew the 3 screws for
attachment with an allen
key (sw 2,5mm) and
extract the cover.
