Service Manual JET3
62 Rev. 1.0
3. Decline the print head into upfront position. Fill up Special Cleaner 77001-00020
into a spray bottle and spray it to the affected parts for cleaning. Together with a small
brush you can easily remove the pollution in the cleaning area.
Important assemblies which will be affected in their functionality during persist ink
deposition:
- 1. Deflection Plates
- 2. Charge Electrode
- 3. Guiding shaft for the Gutter Tube
4. Due to some special ingredients of the cleaner, it is strongly recommended to flush all
the cleaned parts with tap water at the end of the cleaning process.
5. Rinse off the cleaned parts with original solvent again, to avoid remaining of special
cleaner at the assemblies.
2
1
3
