Service Manual JET3
Rev. 1.0 81
13. Replace the nozzle and turn the knurled-head-screw to stop position. Thereby the
cross bolt centre turns on 90° and arrests the nozzle.
Afterwards turn back the knurled-head-screw about one rotation.
14. Close the gutter tube by pushing the button <arrow> (1) and activate the
<Ink-flow-sensor> (2) and switch the button <Ink on> (3).
1 – Button <arrow>
2 – Button <Ink-Flow-Sensor>
3 – Button <Ink on>
1
3
2
