Service Manual JET3
Rev. 1.0 89
5. Open the allen screw (1,5 metric) from the drop production unit, until it is possible to
bring it into the service-position. Then close the screw until the unit is locked.
6. Touch the <Jet adjust> button (1). Now the gutter tube is moving automatically to an
pre defined service-position (4200) (2).
1 – Button <Jet Adjust>
2 – Display field <Service Position>
1
2
