Leica mojo 3D User Manual

Leica mojo3D, System Overview 15
1.3 Features and Specifications
1.3.1 mojo3D Hardware
mojo3D hardware
features
• Simple installation, with RAM mount and colour-coded quick-install antennas
• Integrated L1 GPS receiver
• Integrated cell modem, CDMA or HSDPA depending on region ordered
• 12 volt operation
• Internal storage for waylines, worked areas, and settings
a) USB interface for data transfer
b) Power button
c) 7" colour touch screen
d) Port expansion connector
e) Connector for GPS antenna, blue
f) Connector for cell modem antenna,
purple
g) Power connector
h) Cover for SIM card slot
i) RAM mount - ball
a cb
g
d
e f
h i
mojo3D_002

Leica mojo 3D Specifications

General

Brand	Leica
Model	mojo 3D
Category	GPS
Language	English
