Leica mojo3D, Technical Data

15.4.2 Cellular Antenna Technical Data

Specifications

Type Description

Dimensions • Length: 115 mm

• Width: 22 mm

• Thickness: 4 mm

Weight 56 g

Compatibility • Frequency Range: 824-960 MHz, 1710-1990 MHz

• Bandwidth: 136/280 MHz

• V.S.W.R.: < 1.5

• Gain: 2 dBi

• Maximum power input: 60 W

• Input impedance: 50 

Antenna type Dipole

Polarization type Vertical

Length 3 metre

Connector Fakra (Bordeaux; Key: D Type)

Cable type RG174

Default Chapter1
- User Manual1
- Table of Contents4
- Leica Mojo3D, Table of Contents6
- Leica Mojo3D, Table of Contents8
- Leica Mojo3D, Table of Contents10
1 System Overview12
- General Mojo3D System Information12
- Components of the Mojo3D System13
- Features and Specifications15
2 System Installation20
- Before Installation20
- Mojo3D Installation22
- Antenna Installation25
- SIM Card Installation29
3 Running the Mojo3D for the First Time32
- Starting up32
- Setting the Screen Calibration34
- Initial Setup Wizard35
- Menu Buttons at Right of Screen49
- Menu Buttons at Left of Screen51
- Specifying Data for Display52
- Zoom Buttons54
- View Modes55
- Error Notifications56
- Running the Setup Wizard at any Time60
- Changing System Settings61
- Vehicle Setup62
- Attached Device Selection63
- NMEA Configuration65
- Feature Unlock66
4 Setting Guidance Types68
- AB Parallel Guidance68
- A+ Heading Guidance70
- Fixed Contour Guidance72
- Pivot Guidance74
- Ultimate Curve Guidance76
- Stop Guidance79
- Guidance Management80
- Field Offset99
- Nudge101
5 Auto-Steer102
- Engage Auto-Steer102
- Tuning Auto-Steer Performance106
- Stationary Engage and Reverse Steering117
- Testing Auto-Steer123
6 Treatments128
- Starting a New Treatment129
- Load a Stored Treatment130
- Changing a Treatment Name131
- Creating a PDF Report of a Treatment132
- Deleting a Treatment134
- Exporting Treatment Data136
- Importing Treatment Data142
7 Automatic Section Control146
- Section Control Latency147
  - Calibrating the Section Control Latency Value148
  - Troubleshooting Latency Problems150
- Setting the Overlap Limit153
- Setting the Low-Speed Shutoff155
- Section Override Control157
8 Field Boundary158
- Create a New Field Boundary158
- Load a Stored Field Boundary160
- Changing a Field Boundary Name161
- Deleting a Field Boundary162
- Exporting Field Boundary Data163
- Importing Field Boundary Data169
9 Vehicles and Implements178
- Saving a Vehicle or Implement Configuration179
- Load a Vehicle or Implement Configuration181
- Renaming a Vehicle or Implement Configuration183
- Deleting Vehicle or Implement Configurations186
- Exporting Vehicle or Implement Configurations191
- Importing Vehicle and Implement Configurations195
10 Correction Sources202
- Network DGPS203
- Sbas209
- Gl1Detm211
- Network RTK215
- RTK Base Station (Internal Radio)221
11 NMEA Output226
- Configuring NMEA Output227
- Logging NMEA Data to USB230
- NMEA Sentences Available232
12 Virtual Wrench™ Remote Service234
- Virtual Wrench234
- Making a Service Request235
- Upgrading Software from Virtual Wrench236
- Upgrading Software Via USB Flash Drive238
- Restoring Previous Software Version240
- Backing up Current Software242
- Serial Numbers and Other System Information244
13 Care and Transport246
- Transport246
- Storage246
- Cleaning and Drying247
14 Safety Directions248
- General Introduction248
- Intended Use249
- Limits of Use251
- Responsibilities251
- Hazards of Use253
- Electromagnetic Compatibility (EMC)259
- FCC Statement, Applicable in U.S262
- ICES-003 Statement, Applicable in Canada263
- Labelling264
15 Technical Data268
- Mojo3D Display Technical Data268
- Mojo3D GPS Receiver Technical Data271
- Wireless Modules Technical Data273
  - HSDPA Wireless Module Technical Data273
  - CDMA Wireless Module Technical Data275
- Antennas Technical Data277
- Mojoxact Technical Data289
- Mojoxact GPS Receiver Technical Data292
- Mojoxact Plus Technical Data294
- Mojoxact Plus GPS Receiver Technical Data297
- Conformity to National Regulations299
16 International Limited Warranty, Software License Agreement306
Appendix A Mojo3D Enhancements308
- Mojo3D with Single Section Control308
- Mojo3D with Multi Section Control Kit313
- Mojo3D with Geopro Antenna320
- A.5 Redeeming a System Option Voucher320
- Mojo3D with Mojoxact Kit325
- Redeeming a System Option Voucher364
Appendix B Formatting USB Flash Drives366
Appendix Cgnu General Public License372
Appendix D Glossary of Terms374
