Leica mojo 3D User Manual

278
Leica mojo3D, Technical Data
LNA/Filter • LNA Gain (without cable): 13 dB/26 dB/28 dB/other
• Typical Noise Figure: 1.5 dB
• Filter Out Band Attenuation: (f
0
= 1575.42 MHz)
• 7 dB Min f
0
± 20 MHz
• 20 dB Min f
0
± 50 MHz
• 30 dB Min f
0
± 100 MHz
• V.S.W.R.: < 2.0
• DC voltage: 2.7 V/3.0 V/3.3 V/5.0 V/3.0 V to
5.0 V/other
• DC current: 5 mA/11 mA/15 mA max
Dimensions of base • Lenghth: 44 mm
• Width: 35.5 mm
• Height: 14 mm
Weight of base < 110 g
Base mounting method Magnetic
Antenna length 5 metre
Antenna type Patch
Type Description
