Leica mojo 3D User Manual

28
Leica mojo3D, System Installation

• System performance may fail or be degraded if cables are cut, kinked or unduly
bent
• Cables should be routed neatly back to the mojo3D. The antenna adhesive
backing is very strong. If unsure of the mounting position and removal may be
required only peel back a small amount of backing tape.
Connect the purple cell modem antenna
cable to the purple connector on the rear of
the mojo3D display. The antenna connectors
and sockets on the Leica mojo3D are colour
coded to ensure correct connection.
mojo3D_009
