298
Leica mojo3D, Technical Data
Data rate • Measurements: Up to 100 Hz
• Position: Up to 20 Hz
Time to first fix • Cold Start: 50 s
Typical value, with no almanac or ephemerides, and no approximate position or
time.
• Hot Start: 35 s
Typical value, with almanac and recent ephemerides saved and approximate posi-
tion and time entered.
Signal re-acquisi-
tion
L1: <0.5 s (typical)
L2: <1.0 s (typical)
Time accuracy 20 ns RMS
Time accuracy does not include biases due to RF or antenna delay.
Velocity accuracy <0.05 m/s RMS
Velocity <515 m/s
US export licensing restricts operation to a maximum of 515 m/s.
Antenna LNA
power output
• Output Voltage: 5 V (nominal)
• Maximum Current: 100 mA
