324
Leica mojo3D, mojo3D Enhancements
The cables must not be cut, kinked or bent tightly, as their performance will be
degraded and system failure may result.
Cables should be routed neatly back to the mojo3D.
The antenna must be mounted horizontally and not on an angle to ensure best
signal reception possible.
4. Connect the blue GPS antenna cable to the
blue connector on the rear of the mojo3D
display.
5. Connect the purple cell modem antenna
cable to the purple connector on the rear of
the mojo3D display.
GeoPRO_004
54
