Leica mojo3D, mojo3D Enhancements 337
1. Attach the black GeoPRO GPS antenna cables (Blue and Purple plugs) to the Blue
and Purple antenna sockets on the back of the mojo3D.
2. Attach the red GPS antenna cables (Green and Red plugs) to the Green and Purple
antenna sockets on the mojoXact.
3. Connect the mojo3D port expansion cable to the mojo3D.
4. Connect the mojoXact port expansion cable to the mojoXact.
5. Connect the green cable on the mojo3D port expansion cable to the green cable
on the mojoXact cable. Note that a mojo3D to mojoXact port expansion exten-
sion cable is available if more length (up to 2m) is required due to the positioning
of the mojo3D and mojoXact.
6. Ensure that the power cable and any other required cables are connected
correctly.
