Leica mojo3D, Setting Guidance Types 73
6. On the dialog box that appears:
• tap to save the wayline to memory.
An on-screen keyboard appears. Enter a name for the wayline, and tap .
OR
• tap to use the wayline without first saving it to memory.
3. Position your vehicle in the field at the point where you want to
start (waypoint A), and tap the A point button.
4. Drive along the contour. At least 30 m (100 feet) must be travelled before
waypoint B can be entered.
To record a straight line segment: Tap to start the straight line, then
tap to continue recording the contour.
5. Tap the B point button on screen when at the end of the contour
to complete the recording.
