3.RemovethePCIcardbracketassemblybydoingthefollowing:

a.Pressthereleasetab1inthedirectionshownandthencarefullyliftthePCIcardbracketassembly

slightlyupwarduntilthetwomountingstuds2onthechassisareinthecentralpositionofthe

correspondingholesinthePCIcardbracketassembly.

Figure38.ReleasingthePCIcardbracketassembly

b.CarefullymovethePCIcardbracketassemblytothetopsideofthechassisuntilthePCIcard

bracketassemblyisreleasedfromthemountingstudsonthechassis.Then,liftthePCIcardbracket

assemblyoutofthechassis.

Figure39.RemovingthePCIcardbracketassembly

92ThinkServerTS430UserGuide
