•Eachoftheharddiskdrivebay(5to8)isusedforinstallinga3.5-inchnon-hot-swapharddiskdrives.

Note:Thenumberoftheinstalledharddiskdrivesvariesbymodel.

•Forinformationaboutthesupportedexpansioncard,see“Systemboardcomponents”onpage45

•Dependingonthemodel,yourservermightcomewithascrew-secured,non-hot-swappowersupply

assemblyoroneortwohot-swapredundantpowersupplies.

•Formoreinformationaboutthememorymodules,see“Memorymoduleinstallationrules”onpage94.

Hot-swapharddiskdrivestatusLEDs

Thistopicappliesonlytoservermodelswithhot-swapharddiskdrives.

Note:Dependingonthemodel,yourservermightlookslightlydifferentfromtheillustrationsinthistopic.

Eachhot-swapharddiskdrivehastwostatusLEDsonthefront.Unlockandopenthefrontdoortogain

accesstotheharddiskdrivesandviewthestatusLEDs.

Figure15.3.5-inchhot-swapharddiskdrivestatusLEDs

32ThinkServerTS430UserGuide
