13.AlignthetopedgeoftheEMI-protectivepanelwiththetopsideoftheharddiskdrivecageandthen
pivottheEMI-protectivepaneldownuntilitsnapsintoposition.
Figure78.InstallingtheEMI-protectivepanel
14.Closeandlockthefrontdoor.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheinstallation,goto“Completingthepartsreplacement”onpage170.Then,youmight
needtorecongureRAIDforyourserver.See“ConguringRAID”onpage73.
Replacingthehot-swapharddiskdrivebackplane
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstandingthe“Safetyinformation”
onpageiiiand“Guidelines”onpage85.
Thistopicprovidesinstructionsonhowtoreplacethehot-swapharddiskdrivebackplane.
Thistopicappliesonlytoservermodelsthathavehot-swapharddiskdrive(s)installed.
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Note:Dependingonthemodel,yourservermightlookslightlydifferentfromtheillustrationsinthistopic.
Toreplacethehot-swapharddiskdrivebackplane,dothefollowing:
1.Removeallmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,disconnectall
powercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedtotheserver.
Chapter6.Installing,removing,orreplacinghardware141
