5.Goto“Completingthepartsreplacement”onpage170.

Installing,removing,orreplacinghardware

Thistopicprovidesinstructionsonhowtoinstall,remove,orreplacehardwareforyourserver.Youcan

expandthecapabilitiesofyourserverbyaddingnewhardwaredevices,suchasmemorymodules,PCI

cards,orotherserveroptions,andmaintainyourserverbyreplacingthefailinghardwaredevices.

Ifyouarehandlingaserveroption,refertotheappropriateinstallationandorremovalinstructionsinthis

topicalongwiththeinstructionsthatcomewiththeoption.

Notes:

1.UseonlypartsprovidedbyLenovo.

2.Dependingonthemodel,yourservermightlookslightlydifferentfromtheillustrationsinthistopic.

Installingorremovingamemorymodule

Thistopicprovidesinstructionsonhowtoinstallorremoveamemorymodule.

ForalistoftheThinkServermemorymoduleoptions,gotohttp://www.lenovo.com/thinkserver.Clickthe

ProductstabandthenclickOptions➙ThinkServerMemorytoviewtheinformation.

Note:ThememorymodulesareextremelysensitivetoESD.Makesurethatyoureadandunderstand

“Handlingstatic-sensitivedevices”onpage86

rstandcarefullyperformtheoperation.

Memorymoduleinstallationrules

YourserverhasfourmemoryslotsforinstallingorreplacingDDR3UDIMMswithECCtechnology.

•Supports2GB,4GB,and8GB1333MHzDDR3UDIMMs

•Single-rankordual-rank

•Minimumsystemmemory:2GB(onlyone2GBmemorymoduleinstalledintheDIMMA2slot)

•Maximumsystemmemory:16GB(one4GBmemorymoduleinstalledineachofthefourmemoryslots)

94ThinkServerTS430UserGuide
