Thefollowingillustrationshowsthecomponentsofservermodelswithvetoeight3.5-inchhot-swap
harddiskdrives.
Figure11.Componentsofservermodelswithvetoeight3.5-inchhot-swapharddiskdrives
1IntelligentDiagnosticsModule(availableinsome
models)
13Frontsystemfan1
2Frontpanel
14Frontsystemfan2
3Opticaldrivebay2(withanopticaldriveinstalled
insomemodels)
15Systemboardbattery
4Opticaldrivebay1(withanopticaldriveinstalled)16Low-prolePCIcardbracket
5Harddiskdrivebay7
17MainPCIcardbracket
6Harddiskdrivebay618Expansioncard
7Harddiskdrivebay5
19Heatsinkandfanassembly
8Harddiskdrivebay4
20Systemboard
9Harddiskdrivebay3
21Rearsystemfan
10Harddiskdrivebay222Powersupply
11Harddiskdrivebay1
23Fourmemoryslots(installedmemorymodulesvaryby
model)
12Harddiskdrivebay0
•Formoreinformationabout1to4,see“Frontviewoftheserver”onpage15.
