Backplaneforservermodelswitheight2.5-inchhot-swapharddiskdrivebays
Thistopicprovidesinformationtohelpyoulocatetheconnectorsonthebackplaneforservermodels
witheight2.5-inchhot-swapharddiskdrivebays.
Thefollowingillustrationsshowtheconnectorsonthebackplaneforservermodelswitheight2.5-inch
hot-swapharddiskdrivebays.
Figure21.Frontviewofthebackplaneforservermodelswitheight2.5-inchhot-swapharddiskdrivebays
1Slot0fora2.5-inchSAShot-swapharddisk
drive
5Slot4fora2.5-inchSAShot-swapharddiskdrive
2Slot1fora2.5-inchSAShot-swapharddisk
drive
6Slot5fora2.5-inchSAShot-swapharddiskdrive
3Slot2fora2.5-inchSAShot-swapharddisk
drive
7Slot6fora2.5-inchSAShot-swapharddiskdrive
4Slot3fora2.5-inchSAShot-swapharddisk
drive
8Slot7fora2.5-inchSAShot-swapharddiskdrive
Figure22.Rearviewofthebackplaneforservermodelswitheight2.5-inchhot-swapharddiskdrivebays
18-pinpowerconnector
Usedtoconnectapowercable.
