Thefollowingillustrationsshowtheconnectorsonthebackplaneforservermodelswithfour3.5-inch
hot-swapharddiskdrivebays.
Figure19.Frontviewofthebackplaneforservermodelswithfour3.5-inchhot-swapharddiskdrivebays
1Slot0fora3.5-inchSATAorSAShot-swaphard
diskdrive
3Slot2fora3.5-inchSATAorSAShot-swapharddiskdrive
2Slot1fora3.5-inchSATAorSAShot-swaphard
diskdrive
4Slot3fora3.5-inchSATAorSAShot-swapharddiskdrive
Figure20.Rearviewofthebackplaneforservermodelswithfour3.5-inchhot-swapharddiskdrivebays
18-pinpowerconnector
Usedtoconnectapowercable.
2Mini-SASsignalcableconnector
Usedtoconnectthemini-SASconnectorononeendofthemini-SASsignalcable.
32ThinkServerTS440UserGuide
